6
VI.UH.R1.80
Produced by Danfoss Floor Heating Hydronics 01.2006
Instruction CF-RF Room Thermostat with InfraRed Floor Sensor
Room Thermostat installation status
• Satisfactory - LED goes OFF
• Not satisfactory - LED ashes 5 times
Note: A Room Thermostat can be assigned to sev-
eral outputs if needed by repeating the installation
process.
3. Temperature Settings
Digital Display - g. 1
Set value adjustment
Minimum temperature limitation
Maximum temperature limitation
Lock icon (settings locked from
Remote Controller, CF-RC)
Transmission link icon
Low battery indicator
Alarm icon
Timer icon (time program is active from
Remote Controller, CF-RC)
Room temperature
Floor surface temperature
