Danfoss 5000 Flux - Page 43

VLT
®
5000/5000 Flux/6000 HVAC/8000 AQUA PROFIBUS
MG.90.D1.02 – VLT is a registered Danfoss trademark
43
PNU Parameter Factory setting Range Changes Conversion
# description during Index
operation
500 Address 1 1 - 126 Yes No
501 Baudrate 9600 Baud Yes No
502 Coasting Logic or Yes Yes
503 Quick-stop Logic or Yes Yes
504 DC-brake Logic or Yes Yes
505 Start Logic or Yes Yes
506 Reversing Logic or Yes Yes
507 Selection of setup Logic or Yes Yes
508 Selection of speed Logic or Yes Yes
509 Bus jog 1 200 rpm 0.0 - parameter 202 Yes Yes
510 Bus jog 2 200 rpm 0.0 - parameter 202 Yes Yes
512 Telegram profile FC Drive No Yes
513 Bus time interval 1 sec. 1 - 99 s Yes Yes
514 Bus time interval function Off Yes Yes
515 Data read-out: Reference % No No
516 Data read-out: Reference unit No No
518 Data read-out: Frequency No No
520 Data read-out: Current No No
521 Data read-out: Torque No No
522 Data read-out: Power, kW No No
523 Data read-out: Power, HP No No
524 Data read-out: Motor voltage No No
525 Data read-out: DC link voltage No No
526 Data read-out: Motor temp. No No
527 Data read-out: VLT temp. No No
528 Data read-out: Digital input No No
529 Data read-out: Terminal 53, analogue input No No
530 Data read-out: Terminal 54, analogue input No No
531 Data read-out: Terminal 60, analogue input No No
532 Data read-out: Pulse reference No No
533 Data read-out: External reference % No No
534 Data read-out: Status word, binary No No
535 Data read-out: Brake power/2 min. No No
536 Data read-out: Brake power/sec. No No
537 Data read-out: Heat sink temperature No No
538 Data read-out: Alarm word, binary No No
539 Data read-out: VLT control word, binary No No
540 Data read-out: Warning word, 1 No No
541 Data read-out: Extended status word No No
557 Data read-out: Motor RPM No No
558 Data read-out: Motor RPMxscaling No No
6
5
5
5
5
5
5
5
5
6
6
5
5
5
3
4
6
7
3
7
7
6
6
5
5
5
3
3
3
7
3
6
6
6
5
7
6
7
7
4
4
4-Setup
Data
type
■ Parameter list VLT 5000 Flux
0
0
0
0
0
0
0
0
0
-1
-1
0
0
0
-1
-3
-1
-2
-1
-1
-2
-1
0
0
0
0
-2
-2
-5
-1
-1
0
2
2
0
0
0
0
0
0
-2
Parameter list
