Danfoss AK-CC 750A - Ordering

40 RS8HP102 © Danfoss 2018-09 AK-CC 750A
Type Function Application Code no.
Example
continued
Operation
AK-ST 500 Software for operation of AK controllers AK-operation 080Z0161 x
- Cable between PC and AK controller USB A - USB B (standard IT cable) - x
Accessories Power supply module 230 V / 115 V to 24 V
AK-PS 075 18 VA
Supply for controller
080Z0053 x
AK-PS 150 36 VA 080Z0054
Accessories External display that can be connected to the controller module. For showing, say, the appliance temperature
EKA 163B Display 084B8574 xxx
EKA 164B Display with operation buttons 084B8575
MMIGRS2 Graphic display with operation 080G0294
- Cable between EKA display and controller
Length = 2 m 084B7298 xxx
Length = 6 m 084B7299
-
Cable between graphic display type MMIGRS2 and
controller (controller with RJ11 plug)
Length = 1.5 m 080G0075
Length = 3 m 080G0076
Accessories Communication modules for controllers where modules cannot be connected continuously
AK-CM 102 Communication module
Data communication for external extension mod-
ules
080Z0064
Type Function Application Language Code no.
Example
continued
AK-CC 750A Controller for evaporator control 1, 2, 3 or 4 sections
English, German, French,
Dutch, Italian, Spanish, Portu-
guese, Danish, Finnish, Polish,
Russian, Czech
080Z0140
X
1. Controller
2. Extension modules and survey for inputs and outputs
3. AK operation and accessories
Ordering
Type Analog
inputs
On/Off outputs On/off supply voltage
(DI signal)
Analog
outputs
Stepper
outputs
Module
with
switches
Code no.
Example
continued
For sensors,
pressure
transmitters
etc.
Relay
(SPDT)
Solid state Low volt-
age
(max. 80 V)
High volt-
age
(max. 260
V)
0-10 V d.c. For valves
with step
control
For override
of relay
outputs
With screw
terminals
Controller 11 4 4 - - - - -
Extension modules
AK-XM 101A 8 080Z0007 x
AK-XM 102A 8 080Z0008
AK-XM 102B 8 080Z0013
AK-XM 103A 4 4 080Z0032
AK-XM 204A 8 080Z0011
AK-XM 204B 8 x 080Z0018
AK-XM 205A 8 8 080Z0010
AK-XM 205B 8 8 x 080Z0017
AK-XM 208C 8 4 080Z0023
The following extension module can be placed on the PC board in the controller module.
There is only room for one module.
AK-OB 110 2 080Z0251
