AME 10, AME 11
ENGLISH
Safety Notes
To avoid injury of persons and
damages to the device, it is absolutely
necessary to read and observe these
instructions carefully.
Necessary assembly, start-up, and maintenance
work must be performed by qualified and
authorized personnel only.
Please comply with the instructions of the
system manufacturer or system operator.
Disposal instruction
This product should be dismantled
and its components sorted, if possible,
in various groups before recycling or
disposal.
Always follow the local disposal regulations.
Mounting ❶
Fix the actuator on the valve.
Wiring ❷
Control signal
Control signal from the controller must be
connected to terminals Y (input signal) and SN
(common) on the AME printed board.
Output signal
Output signal from the terminal X can be used
for indication of the current position. Range
depends on the DIP switch settings.
Supply voltage
Supply voltage (24 V~ −15 to +10 %, 50/60 Hz)
must be connected to the terminals SN and SP.
DIP switch settings ❸
U I
2 V_--- V 0 V_--- V
Direct Inverse
--- Sequential
0(2)_5(6) V 5(6)_10 V
Proportional 3 point/RL
LOG. flow LIN. flow
100 % k
VS
RED. k
VS
Reset Reset
Factory settings:
ALL switches are on OFF position! ①
Note: All combinations of DIP switches are
allowed. All functions that are selected are
added consecutively. There is only one logic
override of functionalities i.e. the switch No.6
Proportional / 3 point, which sets actuator to
ignore control signal and works as a “simple”
3-point actuator.
SW1: U/I ②
Actuator can responde to a voltage or current
control signal. With switch No.1: U/I actuator can
be set either to operate with a voltage control
signal (actuator responds to signal between
0-10 V), or current control signal (actuator
responds to signal between 0-20 mA).
Factory setting:
voltage control signal (0-10 V).
SW2: 2 V-10 / 0 V-10 ③
Actuator can be set to response on a control
signal from 2 V, or 0 V. If the actuator is set to
current signal then it responds to control signal
from 4 mA or 0 mA.
Factory setting is:
2-10 V.
SW3: Direct/Inverse ④
Actuator can be set for spindle to travel
downwards on rising control signal (DIRECT), OR
for spindle to travel upwards on rising control
signal (INVERSE).
Factory setting is:
DIRECT
SW4: ---/Sequential ⑤
Two actuators can be set to work parallel with
one control signal. If the SEQUENTIAL is set then
an actuator responds to split control signal (see
0(2)-5(6) V/ 6(6)-10 V).
Note: This combination works in combination
with switch No.5: 0(2)-5(6) V/ 6(6)-10 V
SW5: 0(2)-5(6) V/6(6)-10 V ⑥
Note: This function is available if
switch No.4:
--- / Sequential is set.
SW6: Proportional/3 point ⑦
Actuator needs to perform Self
stroking prior changing DIP 6 to ON.
Output signal depends on DIP 2, 3&5
setting.
Actuator can operate in modulating (DIP 6 to
OFF) or in “simple” 3-point mode, if the 3-point
function is selected (DIP 6 to ON).
Connect power supply on terminals SN and SP
terminals.
Factory set DIP 6 to OFF for operating actuator
in Modulating mode.
Actuator’s stem will run to its totally extended
or retracted position by bridging SN signal to
terminals 1 or 3 and will remain in this positron
as long as potential is present.
Set DIP 6 to ON for operating actuator in 3-point
mode.
Look carefully wiring diagram as wiring is
different for controllers with triac output (ECL)
in comparison to controllers with relay output.
Return signal X indicates the correct position.
Note: If 3-point function is selected actuator
does not respond to any control signal on
port Y. It only rises and lowers spindle if power
is supplied on port 1 or 3.
SW7: LOG/LIN - Not in use.
SW8: 100 % k
VS
/Reduced k
VS
- Not in use.
SW9: Reset ⑧
After the actuator has been connected to
power supply, the actuator will start the
self-adjustment procedure. The indicator LED
flashes until self adjustment is finished. The
duration depends on the spindle travel and will
normally last a few minutes. The stroke length
of the valve is stored in the memory after self
adjustment has been completed. To restart
self adjustment, change the position of RESET
switch (switch No. 9). If the supply voltage is
switched off or falls below 80 % in more then
0.1 s, the current valve position will be stored
in the memory and all data remain saved in the
memory also after a power supply cut-out.
Function test
The indicator light shows whether the
positioner is in operation or not. Moreover, the
indicator shows the control status and faults.
Constant light
- normal operation
No light
- no operation or no power supply
Intermittent light (1 Hz)
- self adjusting-mode
Intermittent light (3 Hz):
- power supply too low
- insufficient valve stroke (<20 s)
- end-position cannot be reached.
Dimensions ❹
