Danfoss AME 10 User Manual

© Danfoss | 2019.07 | 5
EI.96.L5.1F
AME 10, AME 11
❸
②
③
④
⑤
⑥
⑦
⑧
❹
121
121
107
min. 200
DN
H
1
H
2
H
3
H
4
mm
15 163 - 159 192
20 163 149 159 192
25 163 155 164 192
32
163
-
169
-
40 - - 174 -
AME 10, AME 11 +
VB 2 (DN 15-25)
H
4
H
1
AME 10, AME 11 +
VM 2 (DN 15-32)
AME 10, AME 11 +
VS 2 (DN 20, 25)
H
2
AME 10, AME 11 +
VMV (DN 15-40)
H
3
AME 10, AME 11 +
AVQM PN 16
see AVQM data sheet
AME 10, AME 11 +
AVQM PN 25
see AVQM data sheet
①
U
I
2 V_--- V
0 V_--- V
Direct
Inverse
---
Sequential
0(2)_5(6) V 5(6)_10 V
Proportional
3 point/RL
LOG. flow
LIN. flow
100 % k
VS
RED. k
VS
Reset
Reset
