Danfoss AME 25 SU User Manual

© Danfoss | 2016.12 | 3
VI.AD.B3.8C
AME 25 SU, AME 25 SD
SN
24 VAC Neutral
SP
0 V Power supply
1
24 VAC Input
3
X 0(2)-10 VDC Output
Wiring for 3-point floating mode
Controller with triacs output
Proportional 3 point/RL
SN 0 V Neutral
SP 24 VAC Power supply
1
24 VAC Input
3
X 0(2)-10 VDC Output
Proportional 3 point/RL
SN 0 V Neutral
SP 24 VAC Power supply
Y
0(2)-10 V
Input
0(4)-20 mA
1
0 V Input
3
X 0(2)-10 V Output
Proportional 3 point/RL
Wiring for 3-point floating mode
Controller with relay output
Wiring for modulating
mode
❸
