Danfoss BasicPlus2 WT-DM Installation Guide

1 Installation Steps
2 Wiring
Installation Guide
WT-DM Installation Instruction
Danfoss Heating Solutions
2
The User Guide can be downloaded from: heating.danfoss.com.
1. Installation must be done by an authorised electrician.
2. The room thermostat should be installed at approx. 1.5 m
above oor and where the eects of sunlight, draught or
other heat sources (eg. TV's) are avoided. See g.1.
3. First of all, carefully remove the cover. See g.2.
4. Connect the wire before mounting the back plate to the
wall box using the enclosed screws. Then mount the cover
to the back plate. See g.3.
1. Dimensions, see g.4.
2. Wiring diagram,see g.5. (S1,S2:oor sensor terminals;A+,B-:
Modbus communication terminals).
3. WT-DM is often used with Danfoss TWA actuator. Depending
on the conditions of power location and actuator type (NC or
GB

Danfoss BasicPlus2 WT-DM Specifications

General

Brand	Danfoss
Model	BasicPlus2 WT-DM
Category	Thermostat
Language	English
