Danfoss BD35F User Manual

3AF322334006818en-000101
Compressors
R134a
R404A/R507 *
R600a **
R290 ***
Code
numbers
Electronic units (voltages & code numbers)
Standard
12-24V DC
101N0212
High Speed
12-24V DC
101N0390
AEO
12-24V DC
101N0340
Solar
10-45V DC
101N0420
AC/DC converter
12-24V DC &
100 -240V AC
101N0510
Automotive
12-24V DC
101N0650
101N08xxx
12V DC
101N0820+0800
(alt.: 101N0830)
101N8xxx
24V DC
101N0820+0810
101N07xx
24V DC
101N0715
Telecom
48V DC
101N0720
Telecom
48V DC
101N0732
BD35F 101Z0200
    
BD35F (inch con.) 101Z0204
    
BD35F-B 101Z0205
   
BD35F-HD.2 101Z0216
  
BD50F 101Z1220
   
BD50F (inch con.) 101Z0203
   
BD80F 101Z0280

BD250GH.2 101Z0406

BD250GH.2 (48V) 101Z0405

BD250GH.2-HD (48V) 101Z0410

BD350GH (12V) 102Z3015
+
BD350GH (24V) 102Z3016
+ 
BD350GH (48V) 102Z3031

BD220CL * 102Z3020
+
BD35K ** 101Z0211
    
BD50K ** 101Z0213

BD80CN *** 101Z0403
   
BD100CN *** 101Z0401

TOOL4COOL® applicable
     
Applications
Compressors
BD1.4F-AUTO.3 BD1.4F-VSD.2 BD1.4F-VSD-HD BD35F BD35F-B BD35F-HD.2 BD35K BD50K BD50F BD80F BD80CN BD100CN BD250GH.2 BD350GH BD220CL
Truck refrigerators
       
Boat refrigerators
       
Bus refrigerators
     
Portable boxes
     
Car minbars (high end)
   
Car minibars
(SUV, MPV)
  
Spot cooling
(e.g. trucks)
 
Van boxes
      
Battery cooling
 
Solar cabinets
     
Compressors
R134a
Code
numbers
Electronic units
Variable Speed (VSD)
12-24V DC
101N2100
Variable Speed (VSD)
w. AC/DC converter
12-24V DC &
100 -240V AC
101N5100
Automotive
12V DC
101N1010
BD1.4F-AUTO.3 109Z0104

BD1.4F-VSD.2 109Z0204
 
BD1.4F-VSD-HD 109Z0250

BD1.4F-VSD.2
(inch connectors)
109Z0206
 
BD1.4F-VSD-HD
(inch connectors)
109Z0251

TOOL4COOL® applicable
  
BD1.4F-VSD.2 (Variable Speed Drive)
The new BD1.4F-VSD.2 is 60% smaller than previous models
and weighs in at only 2.3 kilos. Perfect for 10-30 litre in car
/ van / boat cabinets or portable boxes that need to fit into
tight spaces without compromising storage space.
Specially designed for maximum efficiency and reliability
this powerhouse of a compressor makes it easier than ever
to provide leading class mobile refrigerators.
Enabling the variable speed function increases the system’s
COP. Low energy consumption is good for car/ boat/ van
batteries – as well as the environment. The optimized, low
noise motor ensures outstanding performance when you
want to provide that extra degree of luxury on the move.
The electronic thermostat (NTC sensor support) provides an
accurate temperature while the failure detection allows a
fast fault diagnosis. The computer interface makes it easier
for customization.
BD35F-HD.2, BD250GH.2-HD, BD1.4F-VSD-HD (Heavy
Duty)
BD35F-HD.2, BD250GH.2-HD (48V) and BD1.4F-VSD-HD and
are new versions which can handle extreme vibrations.
BD35F-B (Bus-optimized)
The BD35F-B is a special version optimized for rough vehicle
motions, especially in buses.
BD50K (Isobutane, R600a)
The new BD50K offers 25 % additional cooling capacity
compared to the BD35K compressor.
