Magnetic tracer on crutch unit
Power Supply
Mains Supply 4 x 1,5 V⎓, battery type AA
Tracing Mode
Trace Frequency 1,8 kHz
Gain control knob Adjust to control amplication of tracer signal
Oset control knob Used to compensate for induction of a signal reected by
the pointer indicator.
Volume control knob Adjustment of sound in headphones and ON/OFF unit
Mechanical
Dimensions 160 × 300 × 970 mm
Weight 1,5 kg
IP class IP20
Approvals The equipment has been tested by Intertek according to
EN/IEC 61010-1 with amendments, EN/IEC 61010-2-030
with amendments and EN/IEC 61326-1 with amendments.
Environment For HVU tracer mode: indoor and outdoor use.
Temperature range: 5 ºC to 40 ºC.
Magnetic tracer - Hand held unit
Power Supply
Mains Supply 1 x 9 V⎓, battery type PP3 / 6F22 / 6LF22
Tracing Mode
Trace Frequency 1,8 kHz
Volume control knob Adjustment of sound in headphones and ON/OFF unit
Other
Mechanical
Dimensions 65 x 105 x 40 mm
Weight 0,2 kg
IP class IP20
Approvals The equipment has been tested by Intertek according to
EN/IEC 61010-1 with amendments, EN/IEC 61010-2-030
with amendments and EN/IEC 61326-1 with amendments.
Environment For HVU tracer mode: indoor and outdoor use.
Temperature range: 5 ºC to 40 ºC.

Danfoss DEVItector II V2 Specifications

General

Brand	Danfoss
Model	DEVItector II V2
Category	Security Sensors
Language	English
