DEVItector™ II V2User Guide
BC421332622232en-01010128 | ©Danfoss | FEC | 2022.07
11. Data sheet
High Voltage Unit (HVU)
Equipment specication Class I
Installation category II
Pollution degree 2
Power Supply
Mains Supply 220–240 V~, 50–60 Hz, 1000 VA
Voltage uctuations may not exceed ±10% of nominal value
Fuse at mains connector 4TAL 250V EN/IEC 60127-2
At transformer secondary coils 5A, 2×2A, 0.5A
Burning Mode
Burning DC Voltages (No load) 41, 82, 123, 164, 205, 246, 287, 328, 369 V⎓
Short Circuit Currents Limited by Software to 3 A⎓
Measuring Readout on 2x20 character Vacuum Fluorescent Display:
Probe Voltage: 0–400 V⎓
Probe Current: 0–3.00 A⎓
Probe High Voltage Pulse: 0–10 kV
High Voltage Pulse 10 kV
High Voltage Pulse Energy 0,38 J
Max. Pulse Energy 70 J
Number of High Voltage Pulses 1–3 pulses/sec.
Tracing Mode
Trace Frequency 1,8 kHz
Tracing Voltages (No load) 5, 10, 15, 20, 25, 30, 35, 40 V RMS
Short Circuit Currents 80, 160, 240, 320, 400, 480, 560, 640 mA RMS
Measuring Readout on 2x20 character Vacuum Fluorescent Display:
0–1.00 A RMS
Volume control Adjustment of sound in headphones
Other
Overheat protection Software controlled cut-o at 3 A or at 75 °C.
Safety in Burning Mode Only operable with Safety Key
High Voltage Unit should be ON and Safety Button
should be pressed to proceed the burning process.
Mechanical
Cabinet dimensions 250 x 260 x 380 mm
Weight 17 kg
IP Class IP20
Approvals The equipment has been tested by Intertek according to
EN/IEC 61010-1 with amendments, EN/IEC 61010-2-030
with amendments and EN/IEC 61326-1 with amendments.
Environment For burner and tracer: indoor and outdoor use.
Temperature range: 5 ºC to 40 ºC.
Altitude: up to 2000 m above sea level.
Humidity at 31 ºC: max. 80% linear falling to 50% at 40 ºC .
