DLX 2.0 DLX 2.9 DLX 3.8 DLX 4.6
AC
|S| Rated apparent power 2000 VA 2900 VA 3800 VA 4600 VA
P Rated active power @ cosphi = 1 2000 W 2900 W 3800 W 4600 W
Q Reactive power range 0-1600 VAr 0-2320 VAr 0-3120 VAr 0-3680 VAr
Controlled power factor range 0.8 over-excited, 0.8 under-excided
V
ac,r
Rated output voltage 230 V
V
ac, min
; V
ac
,
max
AC voltage range (P-N. P-P) 230 V±20%, single or split phase
Nominal output current 9.0 A 13.0 A 17.0 A 20.0 A
I
acmax
Max output current 10.5 A 15.2 A 19.7 A 23.0 A
AC current distortion (THD %) 2.59% 3.36%
Cosphi
ac,r
Power Factor (cos φ) 0.8 over-excited, 0.8 under-excided
Night-time power loss < 1 W
f
r
Mains frequency 50 Hz
f
min
, f
max
Grid frequency range 50 Hz ± 5 %
DC
Nominal DC power 2100 W 3000 W 4000 W 4800 W
Max recommended PV power 2625 W 3750 W 5000 W 6000 W
V
dc,r
Nominal voltage DC 220 – 480 V 220 - 480 V
V
mppmin
V
mppmax
MPP voltage-nominal power 230 – 480 V 250 - 480 V
MPP efficiency 99.9%
Max. DC voltage 600 V
Turn on voltage 230 VDC
Turn off voltage 220 VDC
Max current DC 9.5 A 13.5 A 18.0 A 21.0 A
Max. short circuit current DC at STC 9.5 A 13.5 A 18.0 A 21.0 A
Min. on grid power 7 W
Efficiency
Maximum efficiency 97.2 % 97.2 % 97.2 % 97.3 %
CEC efficiency 96.8 % 96.8 % 97.0 % 97.0 %
EU efficiency 96.3 % 96.5 % 96.7 % 96.9 %
Other
Dimensions 610 x 353 x 158 mm(169.5 mm with bracket)
Mounting recommendation Wall bracket
Weight 19 kg 21 kg
Sealing grade IP65
Acoustic noise level < 37dB (A)
Operation temperature range -25 to +65 °C (Possible power derating above +45 °C)
Storage temperature -30 °C to + 80 °C
Relative humidity 4 to 99%
Number of PV string inputs 3
Number of MPP trackers 1
Protection against excessive PV power Yes
Overvoltage category AC / DC Class B / Class B
Reverse polarity protection Yes
Ground fault monitoring Yes
Integral DC switch Yes
PV grounding Field configurable for ungrounded, positive grounded or
negative grounded
Topology High frequency transformer, galvanic isolation
Performance monitoring Graphical colour display with 6 touch sense buttons, 3x
LEDs for visual status indication, Built-in Web Server
PV connection SunClix
AC/grid connection Screw terminals
Ethernet 1 x RJ45
RS-485 / CAN Screw terminals
Functional safety
Safety (protective class) Class I
Islanding detection/ loss of mains Active Frequency Shift
RCD type A recommendation Yes
Indirect contact protection Yes, (Start class I, grounded)
Voltage & frequency surveillance Included
Insulation resistance surveillance Included
DC content of AC current surveillance Included
