Operating envelope data
The Operating envelope for DSH scroll compressors guarantees reliable operations of the compressor for steady-
state operation.
Steady-state operation envelope is valid for a suction superheat within 5K to 30K range at nominal Voltage.
Operating envelope
Figure 5: R410A - DSH090 to DSH184
Condensing temperature (°C)
Evaporating temperature (°C)
Evaporating temperature (°F)
Condensing temperature (°F)
5
10
15
20
25
30
35
40
45
50
55
60
65
70
-40 -35 -30 -25 -20 -15 -10 -5 0 5 10 15 20 25 30
-40 -31 -22 -13 -4 5 14 23 32 41 50 59 68 77 86
41
50
59
68
77
86
95
104
113
122
131
140
149
158
S.H. = 5 K (9°F)
S.H. = 30 K (54°F)
CC-000040
Figure 6: R410A - DSH240 to DSH600
Condensing temperature (°C)
Evaporating temperature (°C)
Evaporating temperature (°F)
Condensing temperature (°F)
5
10
15
20
25
30
35
40
45
50
55
60
65
70
-40 -35 -30 -25 -20 -15 -10 -5 0 5 10 15 20 25 30
-40 -31 -22 -13 -4 5 14 23 32 41 50 59 68 77 86
41
50
59
68
77
86
95
104
113
122
131
140
149
158
S.H. = 5 K (9°F)
S.H. = 30 K (54°F)
CC-000042
Scroll compressors, DSH090 to DSH600 | Operating envelope data
