Danfoss DSH090 Application Guide

Tandem
model
Composition Cp1 + Cp2
Suction
Dis‐
charge
Oil equaliza‐
tion
Outline
drawing
number
Suction
from
Washer inner di‐
ameter
Washer in suction
of
Tandem kit
code
DSH565X
DSH184+DSH381
2"1/8
1" 3/8
1" 3/8
8556260
Left
24mm(0.94inch)
Cp1
120Z0781
Right
24mm(0.94inch)
Cp1
DSH590E
DSH295+DSH295
2"1/8
1" 5/8
1" 3/8
8556228
Left
Not needed
-
120Z0792
Right
DSH620U
DSH240+DSH381
2"1/8
1" 5/8
1" 3/8
8556222
Left
29mm(1.14 inch)
Cp1
120Z0791
Right
29mm(1.14 inch)
Cp1
DSH675U
DSH295+DSH381
2"1/8
1" 5/8
1" 3/8
8556222
Left
31mm(1.22 inch)
Cp1
120Z0796
Right
31mm(1.22 inch)
Cp1
DSH725U
DSH240+DSH485
2"1/8
1" 5/8
1" 5/8
8556207
Left
24mm(0.94inch)
Cp1
120Z0786
Right
24mm(0.94inch)
Cp1
DSH760E
DSH381+DSH381
2"1/8
1" 5/8
1" 3/8
8556223
Left
Not needed
-
120Z0792
Right
DSH780U
DSH295+DSH485
2"5/8
1" 5/8
1" 5/8
8556220
Left
27mm(1.06 inch)
Cp1
120Z0787
Right
27mm(1.06 inch)
Cp1
DSH865U
DSH381+DSH485
2"5/8
1" 5/8
1" 5/8
8556224
Left
30mm(1.18 inch)
Cp1
120Z0788
Right
30mm(1.18 inch)
Cp1
DSH895U
DSH295+DSH600
2"5/8
1" 5/8
1" 5/8
8556250
Left
Not needed
-
120Z0726
Right
DSH970E
DSH485+DSH485
2"5/8
1" 5/8
1" 5/8
8556205
Left
Not needed
-
120Z0785
Right
DSH1085U
DSH485 + DSH600
2"5/8
1" 5/8
1" 5/8
8556248
Left
Not needed
-
120Z0726
Right
38mm(1.5 inch)
Cp2
120Z0821
DSH1200E
DSH600 + DSH600
2"5/8
1" 5/8
2" 1/8
8556247
Left
Not needed
-
120Z0726
Right
Trio models
Table 20: Trio models
Trio model
Composition Cp1 + Cp2
+Cp3
Suction
Dis‐
charge
Oil equaliza‐
tion
Outline
drawing
number
Suction
from
Washer inner di‐
ameter
Washer in
suction of
Trio kit code
DSH420T
DSH140+DSH140 +DSH140
2"1/8
1" 3/8
1" 1/8
8560134
Left
26mm(1.02 inch)
Cp1
120Z0714
25mm(0.98 inch)
Cp3
Right
26mm(1.02 inch)
Cp1
24mm(0.94inch)
Cp3
DSH483T
DSH161+DSH161 +DSH161
2"1/8
1" 3/8
1" 1/8
8560134
Left
26mm(1.02 inch)
Cp1
120Z0714
25mm(0.98 inch)
Cp3
Right
26mm(1.02 inch)
Cp1
25mm(0.98 inch)
Cp3
DSH552T
DSH184+DSH184 +DSH184
2"1/8
1" 3/8
1" 1/8
8560133
Left
26mm(1.02 inch)
Cp1
120Z0714
25mm(0.98 inch)
Cp3
Right
25.5mm(1.00 inch)
Cp1
25mm(0.98 inch)
Cp3
DSH720T
DSH240+DSH240+DSH240
2"5/8
1" 5/8
1" 5/8
8556217
Left
30 mm(1.18 inch)
Cp3
120Z0784
Right
34.5 mm(1.36 inch)
Cp1 & Cp3
120Z0794
DSH885T
DSH295+DSH295+DSH295
2"5/8
1" 5/8
1" 5/8
8556217
Left
30 mm(1.18 inch)
Cp3
120Z0784
Right
34.5 mm(1.36 inch)
Cp1 & Cp3
120Z0794
DSH971T
DSH295+DSH295+DSH381
2"5/8
1" 5/8
1" 5/8
8556317
Left
Not needed
-
120Z0790
Right
Not needed
-
120Z0790
DSH1140T
DSH381+DSH381+DSH381
2"5/8
1" 5/8
1" 5/8
8556229
Left
31 mm(1.22 inch)
Cp1
120Z0783
29 mm(1.14 inch)
Cp3
Right
31 mm(1.22 inch)
Cp1
120Z0782
DSH1245T
DSH381+DSH381 +DSH485
2"5/8
2" 1/8
1" 5/8
8556234
Left
29 mm(1.14 inch)
Cp1
120Z0789
Right
29 mm(1.14 inch)
Cp1
DSH1350T
DSH485+DSH485 +DSH381
3"1/8
2" 1/8
1" 5/8
8556235
Left
29 mm(1.14 inch)
Cp3
120Z0789
Right
29 mm(1.14 inch)
Cp3
Scroll compressors, DSH090 to DSH600 | Mechanical connections
