TwoDHWtanktemperaturesensors,upperandlower.Upper
tanktemperatureisOKbeforelowertanktemperature:
X
=
Time
#1#
=
Startdifference(ID1x195)
#2#
=
DesiredDHWtemperature
#3#
=
Stopdifference(ID1x194)
#4#
=
UpperDHWtanktemperaturesensor
#5#
=
LowerDHWtanktemperaturesensor
#6#
=
DHWheating/chargingactivity
TwoDHWtanktemperaturesensors,upperandlower.Lower
tanktemperatureisOKbeforeuppertanktemperature:
X
=
Time
#1#
=
Startdifference(ID1x195)
#2#
=
DesiredDHWtemperature
#3#
=
Stopdifference(ID1x194)
#4#
=
UpperDHWtanktemperaturesensor
#5#
=
LowerDHWtanktemperaturesensor
#6#
=
DHWheating/chargingactivity
