MENU>Settings>Roomlimit
Infl.-max.(roomtemp.limitation,max.)
1x182
Determineshowmuchthedesiredflowtemperaturewillbeinfluenced
(decreased)iftheactualroomtemperatureishigherthanthedesiredroom
temperature(Pcontrol).
SeeAppendix“ParameterIDoverview
0.0:
Noinfluence
-2.0:
Minorinfluence
-5.0:
Mediuminfluence
-9.9:
Maximuminfluence
X
=
Roomtemperature
#1#
=
Desiredroomtemperature
#2#
=
Negativeinfluence(1x082)whenactualroomtemp.getshigher
thandesiredroomtemp.
#3#
=
Positiveinfluence(1x083)whenactualroomtemp.getslowerthan
desiredroomtemp.
The‘Infl.-max. and'Infl.-min. 'determinehowmuchtheroom
temperatureshouldinfluencethedesiredflowtemperature.
Ifthe‘Infl.factoristoohighand/ortheAdapt.timetoolow,thereis
ariskofunstablecontrol.
Example
Theactualroomtemperatureis2degreestoohigh.
The‘Infl.-max.issetto-4.0.
Theheatcurveslopeis1.8(see'Heatcurve'in'Flowtemperature').
Result:
Thedesiredflowtemperatureischangedby(2x-4.0x1.8)
–14.4degrees.
Inapplicationsubtypes,whereaheatcurveslopevalueisnotpresent,
theheatcurveslopevalueissetto1:
Result:
Thedesiredflowtemperatureischangedby(2x-4.0x1):
–8.0degrees.
MENU>Settings>Roomlimit
Infl.-min.(roomtemp.limitation,min.)
1x183
Determineshowmuchthedesiredflowtemperaturewillbeinfluenced
(increased)iftheactualroomtemperatureislowerthanthedesiredroom
temperature(Pcontrol).
SeeAppendix“ParameterIDoverview
9.9:
Maximuminfluence
5.0:
Mediuminfluence
2.0:
Minorinfluence
0.0:
Noinfluence
Example
Theactualroomtemperatureis2degreestoolow.
The‘Infl.-min.issetto4.0.
Theheatcurveslopeis1.8(see'Heatcurve'in'Flowtemperature').
Result:
Thedesiredflowtemperatureischangedby(2x4.0x1.8)
14.4degrees.
Inapplicationsubtypes,whereaheatcurveslopevalueisnotpresent,
theheatcurveslopevalueissetto1:
Result:
Thedesiredflowtemperatureischangedby(2x4.0x1):
8.0degrees.
114|©Danfoss|2017.09
VI.GU.L2.02
OperatingGuideECLComfort210/296/310,applicationA275/A375
