MENU>Settings>Boiler
Reaction,o.band(outsideband)(A375applications)
1x074
Thesettime(inseconds)determinestheburnercut-in/cut-outwhenthe
boiler/flowtemperatureisoutsidethe‘Bandlimit’IDno.11048.
Twoconditionsmustbemetinordertocut-in/cut-outthenextburnerstep:
•thesettimehaselapsedafterthelatestburnercut-in/cut-out
•theboiler/flowtemperatureisoutsidethebandlimit
SeeAppendix“ParameterIDoverview”
5...6000:
Setthedesiredtime.
Theupperillustrationshowsatypicalsituationforburnerstep
cut-inafterasavingperiod.Thetemperaturedifferencebetween
thedesiredandtheactualboiler/flowtemperatureisrelatively
large,i.e.outsidethebandlimit.
Thelowerillustrationshowsatypicalsituationforburnerstep
cut-out.Thetemperaturedifferencebetweenthedesiredandthe
actualboiler/flowtemperatureisrelativelylarge,i.e.outsidethe
bandlimit.
Ifthe‘Max.Tlimit’(IDno.11049)hasbeenexceeded,thecut-out
oftheburnerstepstakesplaceevery5seconds.
