Danfoss ECL Comfort 310

MENU>Commoncontroller>System>M-busconfig.
Command
5998
CircuitSettingrange
Factorysetting
-
NONE/INIT/SCAN/GATEWNONE
TheECLComfort296/310/310BareM-busmasters.Inordertoverify
connectedenergymeters,differentcommandscanbeactivated.
NONE:
Nocommandactivated
INIT:
Initializationisactivated
SCAN:
Scanningisactivatedinordertosearchforconnected
energymeters.TheECLComfort296/310/310B
detecttheM-busaddressesofupto5connected
energymetersandplacetheseautomaticallyinthe
"Energymeters"section.Theverifiedaddressisplaced
after"Energymeter1(2,3,4,5)"
GATEW:
TheECLComfort296/310/310Bactasagateway
betweenenergymetersandECLPortal.Usedonlyfor
service.
Scantimecantakeupto12minutes.
Whenallenergymetersarefound,thecommandcanbechanged
toINITorNONE.
MENU>Commoncontroller>System>M-busconfig.
M-busaddress
Energymeter1(2,3,4,5)
6000
CircuitSettingrange
Factorysetting
-
0-255255
Thesetorverifiedaddressofenergymeter1(2,3,4,5).
0:
Normallynotused
1-250:
ValidM-busaddresses
251-254:
Specialfunctions.UseonlyM-busaddress254when
oneenergymeterisconnected.
255:
Notused
MENU>Commoncontroller>System>M-busconfig.
Type
Energymeter1(2,3,4,5)
6001
CircuitSettingrange
Factorysetting
-
0-40
SelectingdatarangefromtheM-bustelegram..
0:
Smalldataset,smallunits
1:
Smalldataset,largeunits
2:
Largedataset,smallunits
3:
Largedataset,largeunits
4:
Volumeandenergydataonly
(example:HydroPortPulse)
Dataexamples:
0:
Flowtemp.,returntemp.,flow,power,acc.volume,acc.energy.
3:
Flowtemp.,returntemp.,flow,power,acc.volume,acc.energy,
tariff1,tariff2.
Seealsothe"Instructions,ECLComfort210/310,communication
description"forfurtherdetails.
SeealsoAppendixfordetaileddescriptionof"Type".
VI.GU.L2.02
©Danfoss|2017.09|167
OperatingGuideECLComfort210/296/310,applicationA275/A375
