3.4Monitoringtemperaturesandsystemcomponents
ThissectiondescribesthefunctioningeneralfortheECLComfort
210/296/310series.Theshowndisplaysaretypicalandnot
applicationrelated.Theymightdifferfromthedisplaysinyour
application.
Boilercircuit
Theoverviewdisplayintheboilercircuitensuresaquickoverview
oftheactualand(desired)temperaturesaswellastheactualstate
ofthesystemcomponents.
Displayexample:
49°C
Boilertemperature
(45)
Desiredboilertemperature
25°C
Returntemperature
(35)
Returntemperaturelimitation
ThedisplayexampleisfromanA375applicationwith4boilers.In
theA275applications,thedisplaywillonlyshow1boiler.
Heatingcircuit
Theoverviewdisplayintheheatingcircuitensuresaquick
overviewoftheactualand(desired)temperaturesaswellasthe
actualstateofthesystemcomponents.
Displayexample:
49°C
Flowtemperature
(31)
Desiredflowtemperature
24°C
Returntemperature
(50)
Returntemperaturelimitation
DHWcircuit
TheoverviewdisplayintheDHWcircuitensuresaquickoverview
oftheactualand(desired)temperaturesaswellastheactualstate
ofthesystemcomponents.
Displayexample(heatexchanger):
50°C
Flowtemperature
(50)
Desiredflowtemperature
--
Returntemperature:sensornotconnected
(30)
Returntemperaturelimitation
Displayexamplewithheatexchanger:
