MENU>Settings>Controlparameters
Motorpr.(motorprotection)
1x174
Preventsthecontrollerfromunstabletemperaturecontrol(andresulting
actuatoroscillations).Thiscanoccuratverylowload.Themotorprotection
increasesthelifetimeofallinvolvedcomponents.
SeeAppendix“ParameterIDoverview”
OFF:
Motorprotectionisnotactivated.
Value:
Motorprotectionisactivatedafterthesetactivation
delayinminutes.
Recommendedforductsystemswithvariableload.
MENU>Settings>Controlparameters
Xp(proportionalband)
1x184
SeeAppendix“ParameterIDoverview”
Settheproportionalband.Ahighervaluewillresultinastablebut
slowcontroloftheflow/ducttemperature.
MENU>Settings>Controlparameters
Tn(integrationtimeconstant)
1x185
SeeAppendix“ParameterIDoverview”
Setahighintegrationtimeconstant(inseconds)toobtainaslow
butstablereactiontodeviations.
Alowintegrationtimeconstantwillmakethecontrollerreactfast
butwithlessstability.
MENU>Settings>Controlparameters
Mrun(runningtimeofthemotorizedcontrolvalve)
1x186
‘Mrun’isthetimeinsecondsittakesthecontrolledcomponenttomove
fromfullyclosedtofullyopenposition.
SeeAppendix“ParameterIDoverview”
Setthe‘Mrun’accordingtotheexamplesormeasuretherunning
timebymeansofastopwatch.
Howtocalculatetherunningtimeofamotorizedcontrolvalve
Therunningtimeofthemotorizedcontrolvalveiscalculatedusing
thefollowingmethods:
Seatedvalves
Runningtime=
Valvestroke(mm)xactuatorspeed(sec./mm)
Example:
5.0mmx15sec./mm=75sec.
Rotatingvalves
Runningtime=
Turningdegreesxactuatorspeed(sec./degr.)
Example:90degr.x2sec./degr.=180sec.
VI.GU.L2.02
©Danfoss|2017.09|137
OperatingGuideECLComfort210/296/310,applicationA275/A375
