Danfoss ECL Comfort A368

OperatingGuideECLComfort310,applicationA368
TypicalA368.6application:

TypicalA368.6application:



Listofcomponents:
ECL310
ElectroniccontrollerECLComfort310
S1
Outdoortemperaturesensor
S2
(Optional)Secondaryreturntemperaturesensor,
circuit1.Formonitoringpurpose
S3
Flowtemperaturesensor,circuit1
S4
DHWowtemperaturesensor,circuit2
S5
(Optional)Returntemperaturesensor,circuit1
S6
(Optional)DHWreturntemperaturesensor,circuit2
S7
Differentialpressureswitch,circuit1
S8
(Optional)DHWcirculationreturntemperaturesensor.For
monitoringpurpose
S9
Alarminput
S10
(Optional)Pressuretransmitterorpressureswitch,circuit1
P1
Circulationpump,DHW,circuit2
P3
Circulationpump,heating,circuit1
P4
Rellwaterpump,circuit1
P5
Circulationpump,heating,circuit1
M1
Motorizedcontrolvalve,circuit2
M2
Motorizedcontrolvalve,circuit1
V1
ON/OFFvalve,circuit1,rellwatervalve
A1
Alarm





