ApplicationA375.1(burnersteps5–8):
Terminal
Description
Max.load
48
PhaseforburnerB5
47
B5
BurnerON/OFF4(2)A/230Va.c.*
46
Nottobeused
45
PhaseforburnerB6
44
B6
BurnerON/OFF4(2)A/230Va.c.*
43
Nottobeused
42
PhaseforburnerB7
41
B7
BurnerON/OFF4(2)A/230Va.c.*
40
PhaseforburnerB8
39
B8
BurnerON/OFF4(2)A/230Va.c.*
*Relaycontacts:4Aforohmicload,2Aforinductiveload
54|©Danfoss|2017.09
VI.GU.L2.02
