Danfoss EKE 1C

© Danfoss | Climate Solutions | 2023.10
Danfoss 80G316.10
–/~ +/~ GND Bat+ A1 A2 B1 B2 NO1 C1 NC1 –/~ +/~ GND Bat+ A1 A2 B1 B2 NO1 C1 NC1
–/~ +/~ GND Bat+ A1 A2 B1 B2 NO1 C1 NC1
–/~
+/~
GND Bat+ A1 A2 B1 B2 NO1 C1 NC1
–
+
+
18 V
C1 NO1
Power
C1 NC1
Power
Superheat controller
EKE 1C - 080G5400
AN269954243889en-000905 | 6
EKE 1C - Back board
connection overview
power supply
24 V AC
± 20%
24 V DC
± 20%
2.5 A
T fuse
(optional)
batt
backup
(optional)
ON/OFF
solenoid
valve
Alarm
orange
yellow
red
black
Alarm Relay
Normally open or
normally closed
(optional)
white
black
red
green
ETS 6 valves
ETS / KVS
Colibri® and
CCMT valves
Superheat controller
