Danfoss EKE 347 Installation Guide

2 DKRCI.PI.RP0.C1.02 / 520H8794 © Danfoss A/S (AC-MCI/MWA), 2014-08
4
Connection
AKS 4100/4100U
AKS 41
Connections
upper level
DI1 - main switch
4-20 mA
CANbus connection
to other EKE controllers
plug for
remote display
ModBUS
4-20 mA
24 V DC
yellow
blue
orange
ICAD 1
st
gen
ICAD/ICM
feedback
ICAD 2
nd
gen
blue
24 V AC
L
N
+
–
1
23
yellow
gray
orange
ICAD 1
st
gen (pre 2010)
ICAD 2
nd
gen (2010 +)
yellow
green
brown
brown
white
24 V+ 15 V+ 5 V+ COM AI 5 AI 4 AI 3 AI 2 AI 1 COM COM DI 2 DI 1 COM
R120 CAN H CAN L GND R GND D+ D- COM AO 1
CAN RJ
24 V DC
24 V DC
1
15 16 17 18 19 20 21 22 23 24
2 3 4 5 6 7 8 9 10 11 12 13 14
