Danfoss EKE 347

© Danfoss A/S (RC-MDP/MWA), 2014-08 DKRCI.PI.RP0.C1.02 / 520H8794 3
Connections
lower level
–/~ NO 4 NC 3 C 3 NO 3 NC 2 C 2 NO 2
-/~ +/~
NO 1 C 1 NC 1
POWER
SUPPLY
AKV/AKVA
24 V AC
+/- 20% 15 VA
24 V DC
+/- 20% 10 W
–
Common
Normally Open or
Normally Closed
Low Level Alarm
Normally Open or
Normally Closed
High Level Alarm
Normally Open or
Normally Closed
+
37
29
28 27 26 25
36 35 34 33 32 31 30
NC 2 C 2 NO 2
NC 3 C 3 NO 3
NO 1 C 1 NC 1
5
Connection
