• The max. cable distance between the controller and the valve depends on many factors like
shielded/unshielded cable, the wire size used in the cable, the output power for the
controller and the EMC.
• Keep controller and sensor wiring well separated from mains wiring.
• Connecting sensor wires more than specied length may decrease the accuracy of
measured values.
• Separate the sensor and digital input cables as much as possible(at least 10cm) from the
power cables to the loads to avoid possible electromagnetic disturbances. Never lay power
cables and probe cables in the same conduit (including those in electrical panels)
Cable length Wire size min/max (mm
2
)
Power supply and
Battery input
Max 5m
AWG 24-12 (0.34-2.5 mm)
Torque (0.5-0.56Nm)
Analog inputs Max 10m AWG 24-16 (0.14-1.5mm)
Sensor Max 10m AWG 24-16 (0.14-1.5mm)
Stepper valve Max 30m
AWG 24-16 (0.14-1.5mm)
Torque (0.22-0.25Nm)
Digital input Max 10m AWG 24-16 (0.14-1.5mm)
Digital output Max 10m AWG 24-16 (0.14-1.5mm)
Cabling
Stepper valve connector
ETS/KVS/CCM/ CCMT/CTR/ CCMT L
(Using Danfoss M12 Cable)
ETS 8M
Bipolar
ETS 6
A1 White Orange Orange
A2 Black Yellow Yellow
B1 Red Red Red
B2 Green Black Black
Not connected - - Grey
• All valves are driven in a bipolar mode with a 24 V supply chopped to control the current
(Current driver).
• The stepper motor is connected to the “Stepper Valve” terminals (see terminal assign
ment) with a standard M12 connection cable.
• To congure stepper motor valves other than Danfoss stepper motor valves, the correct
valve parameters must be set as described in the Valve conguration section by
selecting user dened valve.
AN433741508202en-000203 | 8

Danfoss EKE Specifications

General

Category	Industrial Equipment
Supply voltage	24 V AC/DC
Enclosure rating	IP20
Mounting	DIN rail
Type	Electronic Controller
Communication	Yes
Input	Temperature Sensor
