General features and warning
Plastic housing features
• DIN rail mounting complying with EN 60715
• Self-extinguishing V0 according to IEC 60695-11-10 and glowing/hot wire test at 960 °C according
to IEC 60695-2-12
Display Structure
LED Alarm and Warning
2 Sec 1 Sec
0 Sec
1 Valve closed
2 Valve closing
3 Valve idle on target
4 Valve idle on target
5 Valve opening
6 Valve open
Valve open circuit or valve driver heat problem
Normal valve operation
Valve position by LED indication
Alarm/Warning LED indication
Valve type not dened
-/AC +/AC PE
Powe r
Power
No Alarm/Warning A/&B
Alarm/Warning A or B
5 Sec initial boot
2 Sec 1 Sec 0 Sec
CIRCUIT
EXIT
ARROW UP
ARROW DOWN
ENTER
TEXT/VALUE
UNIT
ALARM
AN433741508202en-000203 | 9

Danfoss EKE Specifications

General

Category	Industrial Equipment
Supply voltage	24 V AC/DC
Enclosure rating	IP20
Mounting	DIN rail
Type	Electronic Controller
Communication	Yes
Input	Temperature Sensor
