Crimping Barrel Field Crimp Style Hose Assemlies
Skiving is not required with field crimp fittings. The socket is pre-crimped to the nipple so the fitting can simply be pushed onto the hose
and crimped.
When crimping field crimp style hose assemblies, simple procedures must be followed when locating these assemblies in the crimp die
cage. Reference hose preparation page 9, paragraphs 2 and 3.
SCRIBE MARK ON SOCKET
