Danfoss FT1330 - Electrical Schematics

Danfoss FT1330 Crimp Machine Operator’s Manual
38 | © Danfoss FT1330 Crimp Machine Operator’s Manual | 2023.02.
AQ439269212774en-000101
230V Electrical Schematic
DETAIL NUMBER PART NUMBER DESCRIPTION NUMBER REQUIRED
1 FT1330-2-5-1 Manual Motor Starter 1
2 FT1330-2-5-2 Fuse 1
3 FT1330-2-5-3 Transformer 1
4 FT1330-2-5-4 Foot Switch 1
5 FT1330-2-5-5 Push Button, Contact Block, Legend Plate 1
6 FT1330-2-5-6 Linear Transducer With Connector 1
7 FT1330-2-5-7 3 Digit Knobpot 1
8 FT1330-2-5-8 Control Card 1
9 FT1330-2-5-9 Card Connector 1
10 FT1330-2-5-10 Resistor 1
11 FT1289-2-5-21 Transformer 1
12 FT1289-2-5-24 Plug, 230V 1PH 1
