FT1330 MODEL A
CAPABILITIES
• MATCHMATE PLUS BRAIDED THRU -16, SPIRAL THRU -12
• BARREL FIELD CRIMP THRU -20
• FLAT FIELD CRIMP THRU -16
• FLAT CRIMP 2 WIRE BRAID THRU -20
• FLAT CRIMP 4 WIRE SPIRAL THRU -16 (EXCEPT FC254 & FC273)
DIE SIZE
• DIES FOR NEW FT1330-275-NOS CAGES ARE 3/4“ WIDE WITH A CRIMP LENGTH OF 1.600”
• DIES FOR OBSOLETE FT1330-200-NOS CAGES ARE 9/16’* WIDE WITH A CRIMP LENGTH OF 1.500”.
POWER UNIT
• 1 H.P./ 4,500 PSI/ 1 GPM PUMP
CYLINDER SIZE
• 4” BORE/ 3” STROKE/ 2 1/2” ROD
MAJOR USE
• FIELD CRIMP
COMMENTS
• SOME UNITS WILL HAVE 5” CYLINDERS, BUT EXISTING CRIMP RINGS, WHICH WILL STILL MAKE THEM MODEL A. A LIST OF SERIAL
NUMBERS WILL BE MADE AVAILABLE TO INDICATE A MODEL WITH A 5” CYLINDER.
