FT1330 Model A Parts list
DETAIL NUMBER PART NUMBER DESCRIPTION NUMBER REQUIRED
1 FT1330-2-2 Power Unit 1
2 FT1330-3-1 Base 1
3 FT1330-3-2 Tool Tray 1
4 FT1330-3-3 Cylinder Cover 1
5 FT1330-3-4 Electrical Box 1
6 FT1330-3-5 Transformer Mounting Block 2
7 FT1330-2-3 Cylinder Assembly 1
8 FT1330-3-6 Bumper 9
9 FT1330-3-7 Grommet 3
10 FT1330-3-8 Top Mat 1
11 FT1330-2-4 Knob 1
12 FT1330-3-10 Spacer Tube 1
13 FT1330-3-11 Push Bar 1
14 FT1330-3-12 Back Stop Adj. Bar 1
15 FT1330-3-13 Spring Plunger 1
16 FT1330-3-14 Backstop 1
17 FT1330-3-15 Spring 1
18 FT1330-3-16 Pressure Plate 1
19 FT1330-3-17 Push Bar 3
20 FT1330-3-18 Shaft Collar 1
21 FT1330-3-19 Spanner Nut 1
22 FT1330-3-20 Push Plate 1
23 **FT1330-2-10 1/4 x .375 Shoulder Bolt 2
24 FT1330-3-21 Transducer Bracket 1
25 FT1330-3-22 Spring 1
26 FT1330-3-23 Cylinder Support 2
27 FT1330-2-5-B Transducer 1
28 FT1330-3-24 Cylinder Bracket 1
29 FF1852T0606S Adapter Straight 1
30 FF1868T0606S Adapter 90° 2
31 FT1330-3-69 Supply Tube 1
32 FT1330-3-70 Supply Tube 1
34 FF2227T0606S Adapter Long 90° 1
35 **FT1330-2-10 1/2-13 x 3.50 Soc Hd Cap Screw 2
36 **FT1330-2-10 1/4-20 x .50 Soc. Set Screw 1
37 FT1330-3-31 Roll Pin (.38 Dia. x 3.00) 2
38 **FT1330-2-10 #6-32 x .25 Soc Hd Cap Screw . 4
39 FT1330-3-44 Aeroquip Decal 1
40 FT1208-3-108 A-TJ Decal 1
41 FT1330-3-42 Vickers Decal 1
42 FT1289-3-60 Caution Decal 1
43 FT1330-3-33 1 /4-20 x .50 Button Hd Cap Screw 2
44 **FT1330-2-10 1/4-20 x .75 Soc Hd Cap Screw 4
