Model A Cylinder Subassembly
DETAIL NUMBER PART NUMBER DESCRIPTION NUMBER REQUIRED
1 FT1330-2-3-1 Head Rod End 1
2 FT1330-2-3-2 Head Blind End 1
3 FT1330-2-3-3 Piston 1
4 FT1330-2-3-4 Crimp Ring 1
5 FT1330-2-3-5 Crimp Insert 1
6 FT1330-2-3-6 Piston Rod 1
7 FT1330-2-3-7 O’Ring 2
8 FT1330-2-3-8 Rod Wiper 1
9 FT1330-2-3-9 O’Ring 1
10 FT1330-2-3-10 Backup Ring 1
11 FT1330-2-3-11 O’Ring 1
12 FT1330-2-3-12 Backup Ring 1
13 FT1330-2-3-13 O’Ring 1
14 FT1330-2-3-14 Retaining Ring 1
15 FT1330-2-3-15 Body 1
16 FT1330-2-3-16 Set Screw 1
17 FT1330-2-3-17 Tie Rod 4
18 FT1330-2-3-18 Tie Rod 2
19 FT1330-2-3-19 Hex Nut 2
20 FT1330-2-3-20 Hex Nut 4
21 FT1330-2-3-21 Plug 1
