Model B Cylinder Subassembly
DETAIL NUMBER PART NUMBER DESCRIPTION NUMBER REQUIRED
1 FT1330-2-8-1 Slyde Ring TJ#7881 -4 1
2 FT1330-2-8-2 Head Blind End TJ #TG52KAB072 1
3 FT1330-2-8-3 Piston TJ #TG53KAB073 1
4 FT1330-2-3-4 Crimp Ring TJ #TX86HG3384 1
5 FT1330-2-3-5 Crimp Insert TJ #TX86HG3384A 1
6 FT1330-2-8-6 Piston Rod TJ #TG82UAB072 1
7 FT1330-2-8-7 Hex Nut TJ #5063-18 2
8 FT1330-2-3-8 Rod Wiper TJ #5026-3 1
9 FT1330-2-8-9 Rod Seal TJ #7623-011 1
10 FT1330-2-8-10 O-Ring Seal TJ #5145-339 1
11 FT1330-2-8-11 GFT Seal TJ #5160-0500 1
12 FT1330-2-8-12 Square Steel TJ #5222-2468 1
13 FT1330-2-8-13 Slyde Ride TJ #7880-1 1
14 FT1330-2-3-14 Retaining Ring TJ #5194-625 1
15 FT1330-2-8-15 Body TJ #TG57KAB072 1
16 FT1330-2-8-16 O-Ring Seal TJ #5145-248 1
17 FT1330-2-8-17 Back Up Ring TJ #5138-AA263 1
18 FT1330-2-8-18 Tie Rod TJ #TX56LAB072 2
19 FT1330-2-8-19 Flat Washer TJ #5060-AB072 4
