Danfoss iC7 Series User Manual

Selection number
Selection name
0
None
2
Even
3
Odd
5.6.5 Resolver (Menu Index 9.7)
P 9.7.1 Excitation Voltage
Description: Set the excitation voltage according to the specifications of the connected resolver (RMS).
Default Value : 5
Parameter Type: Range (2 — 8)
Parameter Number: 4005
Unit: V
Data Type: UINT
Access Type: Read/Write
P 9.7.2 Excitation Frequency
Description: Set the excitation frequency according to the specifications of the connected resolver.
Default Value : 5000
Parameter Type: Range (2000 — 20000)
Parameter Number: 4004
Unit: Hz
Data Type: UINT
Access Type: Read/Write
P 9.7.3 Number of Pole Pairs
Description: Set the number of pole pairs of the connected resolver.
Default Value : 1
Parameter Type: Range (1 — 255)
Parameter Number: 4003
Unit: -
Data Type: UINT
Access Type: Read/Write
AQ390830267692en-000601 / 136R0273 | 43Danfoss A/S © 2023.06
Encoder/Resolver Installation and
Configuration
Functional Extension Options
Operating Guide
