Danfoss iC7 Series User Manual

e30bk469.10
Terminal X101
COM
1
NO
2
3
NC
L1
L2
L3
PE
230 V AC
Terminal X102
COM
4
NO
5
6
NC
Terminal X103
COM
7
NO
8
Illustration 28: Operation above 2000 m (6560 ft) Altitude with Voltage above 50 V AC
e30bk470.10
Terminal X101
COM
1
NO
2
3
NC
L1
L2
L3
PE
24 V DC
230 V AC
Terminal X102
COM
4
NO
5
6
NC
Terminal X103
COM
7
NO
8
Illustration 29: Operation above 2000 m (6560 ft) Altitude with Mixed Voltages
6.6 Parameter Descriptions for Relay Option OC7R0
To set Relay output, see parameter group 5.26.1 General Digital Outputs.
6.6.1 Status (Menu Index 9.3)
P 9.3.1 Digital Relay Word
Description: Shows the digital relay word.
Default Value: NA
Parameter Type: Range (0 — 65535)
Parameter Number: 4909
Unit: -
Data Type: WORD
Access Type: Read Only
AQ390830267692en-000601 / 136R0273 | 47Danfoss A/S © 2023.06
Relay Option Installation and
Configuration
Functional Extension Options
Operating Guide
