Table 3: Master/Slave Status Word Structure
Byte Bits Details
0 0–5
Motor current (%FLC)
(1)
6 Command source
0=Remote LCP, digital input, clock
1=Network
7 1=Ramping (starting or stopping)
1 0 1=Ready
1 1=Starting, running, or stopping
2 1=Tripped
3 1=Warning
4–7 Reserved
1
Motor current (%FLC) shows current as a percentage of the set motor full load current. A value of 63 represents 200% full load current. To convert this value to a readable percentage,
divide by 0.315. For models MCD6-0063B and smaller, this value is 10 times greater than the value shown on the LCP.
4.3 Soft Starter Monitoring I/O Data Structure
Table 4: Structure of Master/Slave Output Bytes Structure
Byte 2
Operating data request (data request numbers 1–16)
Table 5: Structure of Master/Slave Input Bytes in Response to an Operating Data Request
Byte Bit
Byte 2
Echo data request number
Byte 3
Bits 7–1 Reserved Bit 0=1: Invalid data request number
Byte 4
Data value (high byte)
Byte 5
Data value (low byte)
NOTICE
An invalid data request number results in the invalid data request number bit being set to 1.
Data Structures
Installation Guide | PROFIBUS Card
AQ277154583779en-000101 / 175R1181 | 9
Danfoss A/S © 2018.09
