Memory
Mapping
(continued)
VLT 5000 Register Maps (65536 registers total)
Address (Decimal) Description
00001 IND (index word)
00002 Modbus Communications Timeout Value (10 millisecond units)
00003 Drive Communications Timeout Value (10 millisecond units)
00004 – 00009 Reserved
00010
Parameter 001, Language
↓ ↓
00190
Parameter 019, Operating State at Power-up, Local Control
00200 – 09999 Reserved
01000
Parameter 100, Configuration
↓ ↓
01310
Parameter 131, Initial Voltage
01320 – 01999 Reserved
02000
Parameter 200, Output Frequency Range/Direction
↓ ↓
02340
Parameter 234, Motor Phase Monitor
02350 – 02999 Reserved
03000
Parameter 300, Terminal 16, Digital Input
↓ ↓
03460
Parameter 346, Encoder Loss Function
03470 – 03999 Reserved
04000
Parameter 400, Brake Function
↓ ↓
04540
Parameter 454, Dead Time Compensation
04550 – 04999 Reserved
05000
Parameter 500, Address
↓ ↓
05410
Parameter 541, Data Readout: Warning Word 2
05420 – 05999 Reserved
06000
Parameter 600, Operating Data: Operating Hours
↓ ↓
06310
Parameter 631, Nameplate: Communication Option Ordering No.
06320 – 06999 Reserved
07000
Parameter 700, Relay 6, Output Function
↓ ↓
07090
Parameter 709, Relay 9, Off Delay
07100 – 65536 Reserved
Memory
Mapping
(continued)
Status Coils Map (128 coils total)
Address (Decimal) Description
1 – 16
PCD
1
Control word (master
→
slave)
17 – 32
PCD
2
Reference value (master
→
slave)
33 – 48
PCD
1
Status word (slave
→
master)
49 – 64
PCD
2
Given output frequency (slav
→
master)
65 Write memory storage type bit (used with AK), see PKE
66 – 128 Reserved
