Control single-phase AK-RC 101
Parts list
1 Housing back panel in ABS
2 Housing front panel in ABS
3 Front cover in transparent polycabonate
4 Front panel opening hinge
5 Front panel closure screws
6 Board xing screws
7 Automatic fuse/ Cut out switch
8 CPU board
9 Polycarbonate screw cover
10 Terminal for earth connections
