Danfoss OPTYMA Plus Series User Manual

4 BC08728642552802-001001
Manual
Controller Installation
Code
(controller
parameter
o61 )*
Model* Optyma
™
Plus
New Generation
Code-no. Compressor* Refrigerant (controller parameter o30)*
settings are adjustable*
Factory
Presetting
R404A
(19)
R507
(17)
R134a
(3)
R513A
(13)
R407A
(21)
R407F
(37)
R448A
(40)
R449A
(41)
R452A
(42)
1 OP-MPHM007NFP00G 114X4101 NF7MLX R404A x x
2 OP-MPHM010SCP00G 114X4102 SC10MLX R404A x x
3 OP-MPHM012SCP00G 114X4104 SC12MLX R404A x x
4 OP-MPHM015SCP00G 114X4105 SC15MLX R404A x x
5 OP-MPHM018SCP00G 114X4109 SC18MLX R404A x x
6 OP-MPGM034GSP00G 114X4210 GS34MFX R134a x
7 OP-MPHM026GSP00G 114X4214 GS26MLX R404A x x
8 OP-MPHM034GSP00G 114X4229 GS34MLX R404A x x
20 OP-LPHM018SCP00G 114X3109 SC18CLX.2 R404A x x
21 OP-LPHM026GSP00G 114X3217 GS26CLX R404A x x
22 OP-LPQM017MPP00G 114X3118 MPT16LA R452A x x x
22 OP-LPQM026AJP00G 114X3216 CAJ2446Z R452A x x x
22 OP-LPQM074FHP00G 114X3252 FH2511Z R452A x x x
22 OP-LPQM074FHP00E 114X3253 TFH2511Z R452A x x x
22 OP-LPQM048NTP00G 114X3225 NTZ48-5VM R452A x x x
23 OP-LPQM048NTP00E 114X3233 NTZ48-4VM R452A x x x
24 OP-LPQM068NTP00G 114X3241 NTZ68-5VM R452A x x x
25 OP-LPQM068NTP00E 114X3249 NTZ68-4VM R452A x x x
26 OP-LPQM096NTP00E 114X3357 NTZ96-4VM R452A x x x
27 OP-LPQM136NTP00E 114X3365 NTZ136-4VM R452A x x x
28 OP-MPYM008MYP00G 114X4119 MLY80RAb R449A x x x
28 OP-MPYM009MYP00G 114X4120 MLY90RAb R449A x x x
28 OP-MPYM012MPP00G 114X4121 MPT12RA R449A x x x
28 OP-MPYM014MPP00G 114X4122 MPT14RA R449A x x x
28 OP-MPBM018AJP00G 114X4230 CAJ9510Z R449A x x x x
28 OP-MPBM024AJP00G 114X4200 CAJ9513Z R449A x x x x
28 OP-MPBM026AJP00G 114X4212 CAJ4517Z R449A x x x x
28 OP-MPBM026AJP00E 114X4213 TAJ4517Z R449A x x x x
28 OP-MPBM034AJP00G 114X4226 CAJ4519Z R449A x x x x
28 OP-MPBM034AJP00E 114X4227 TAJ4519Z R449A x x x x
28 OP-MPXM034MLP00G 114X4261 MLZ015T5LP9 R449A x x x x x x x x x
29 OP-MPXM034MLP00E 114X4264 MLZ015T4LP9 R449A x x x x x x x x x
30 OP-MPXM046MLP00G 114X4281 MLZ021T5LP9 R449A x x x x x x x x x
31 OP-MPXM046MLP00E 114X4284 MLZ021T4LP9 R449A x x x x x x x x x
32 OP-MPXM068MLP00G 114X4308 MLZ030T5LC9 R449A x x x x x x x x x
33 OP-MPXM068MLP00E 114X4311 MLZ030T4LC9 R449A x x x x x x x x x
34 OP-MPXM080MLP00G 114X4321 MLZ038T5LC9 R449A x x x x x x x x x
35 OP-MPXM080MLP00E 114X4324 MLZ038T4LC9 R449A x x x x x x x x x
36 OP-MPXM108MLP00E 114X4344 MLZ048T4LC9 R449A x x x x x x x x x
37 OP-MPXM125MLP00E 114X4414 MLZ058T4LC9 R449A x
x x x x x x x x
38 OP-MPXM162MLP00E 114X4434 MLZ076T4LC9 R449A x x x x x x x x x
39 OP-LPQM215LLP00E 114X3476 LLZ024T4LC9 R452A x x x
40 OP-LPQM271LLP00E 114X3482 LLZ034T4LC9 R452A x x x
41 OP-MPXM057MLP00G 114X4290 MLZ026T5LP9 R449A x x x x x x x x x
42 OP-MPXM057MLP00E 114X4293 MLZ026T4LP9 R449A x x x x x x x x x
52 OP-MPGM033AJP00G 114X4220 CAJ4511Y R134a x x
55 OP-MPLM028VVZP01E 114X4300 VLZ028TGA R404A x x x x
55 OP-MPPM028VVZP01E 114X4302 VLZ028TGA R449A x x x x x x
56 OP-MPLM035VVZP01E 114X4316 VLZ035TGA R404A x x x x
56 OP-MPPM035VVZP01E 114X4316 VLZ035TGA R449A x x x x x x
57 OP-MPLM044VVZP01E 114X4334 VLZ044TGA R404A x x x x
57 OP-MPPM044VVZP01E 114X4334 VLZ044TGA R449A x x x x x x
Code (controller parameter o61): Kode (regulatorparameter o61) / Code (Reglerparameter o61) / Code (contrôleur paramètre o61) / Code (controller parameter o61)
Model
: Model / Modell / Modèle / Modell
Code-no. : Bestillingsnr. / Art-Nr. / Code n° / Artikelnummer
Compressor
: Kompressor / Verdichter / Compresseur / Kompressor
Refrigerant : Kølemiddel (regulatorparameter o30) / Kältemittel (Reglerparameter o30) / Réfrigérant (contrôleur paramètre o30) / Köldmedium
*Settings are adjustable : indstillinger er justerbare / Werte einstellbar / parameters sont réglables / Inställningarna kan justeras
