Danfoss PAH 20

Parts list PAH 20/25/32/50/63/70/80/100 pumps
56
180R9380 | AQ213286502970en-000701 | IOM PAH 20-100 pumps | 11.2021
180B4121 - Screw & seal kit 180B4122 - Valve plate kit 180B4125 - Piston kit PAH 50-80 180B4493 - Piston kit PAH 100 180B4123 - Piston kit 180B4126- Cylinder Barrel 180B4124 - Cylinder Barrel 180B4127 - Cylinder Barrel CCW 180B4009 - Swash plate kit PAH 50 180B4010 - Swash plate kit PAH 63 180B4011 - Swash plate kit PAH 70 180B4012 - Swash plate kit PAH 80 180B4492 - Swash plate kit PAH 100 180Z0237 - Tool set
Pos. Qnt. Designation Material
- 1 Shaft bush, torpedo -
X
- 1 Press tool for 35 mm
shaft
-
X
- 1 Mounting screw -
X
1 1 Housing AISI 304
2 2 Pin AISI 304
X
3 2 Plug AISI 304
4 2 O-RING NBR
X
31 1 Swash plate Stainless steel (1.4057)
X X X X X
34 2 Pin AISI 304
X
61 1 Cylinder barrel Stainless steel (1.4057)
X X X
64 1 Retainer ball Stainless steel (1.4057)
X X X
65 1 Retainer plate Stainless steel (1.4057)
X X X
66 9 Piston Stainless steel (1.4057)
X X X
67 1 Key AISI 304
X
91 1 Port plate AISI 304/PEEK
X
92 1 Valve plate Stainless steel (1.4057)
X
93 9 Back-up ring PTFE
X X
94 9 O-ring NBR
X X
181 1 Port ange AISI 304
182 1 O-ring NBR
X
183 1 Guide pin AISI 304
184 1 Pin AISI 304
X
186 8 Screw AISI 304
X
187 1 Threaded plug AISI 304
188 1 Threaded plug AISI 304
211 1 Mounting ange AISI 304
212 1 O-ring NBR
X
215 1 Shaft seal AISI 304/NBR
X
218 8 Screw AISI 304
X
219 1 Screw AISI 304
X
220 1 Usit-ring AISI 304/NBR
X
- 1 Service instruction
(180R9098)
X X X X X X X X X X X X X
4. Spare parts list for
PAH 50/63/70/80/100
