4 Technical Specifications
Type Specifications
Pressure sensor Piezo resistive true differential
Pressure range
10 bar
Max. overpressure
Positive side: 15 bar
Negative side: 10 bar
Non-linearity and hysteresis error 0.15% of pressure range
Temperature error 1.5% over ambient and medium temperature
Medium temperature -5 to 90°C
Ambient temperature -5 to 50°C
Storage temperature -5 to 50°C
Pressure connection R21 quick couplers
Batteries 2 x AA NiMH rechargeable
Power consumption Max. 55 mA
Display 128 x 64 monochromatic, backlight
Keyboard 3 keys
Pressure units 11
Flow units 11, incl. US units
k
V
-range 0 to 99999, with 0.1 step
Dimensions 94 x 218 x 35 mm
Weight 600 g, incl. batteries
Cover IP65
Calibration validity 12 months
5 Ordering PFM 100
No. Type Set / pcs Danfoss code no.
1 FPM 100 Measuring Instrument 1 003L8260
6 Spare Part List
No. Type Set / pcs Danfoss code no.
1 Measuring hose, 2 x 1.5 m 1 set 003L8261
2 Needle 1 pcs 003L8262
3 Quick coupling 1 pcs 003L8263
4 Filters 1 set 003L8264
5 Strap 1 pcs 003L8265
User Guide PFM 100 Measuring Instrument
Danfoss A/S
Heating Solutions
Haarupvaenget 11
8600 Silkeborg
Denmark
Phone:+45 7488 8000
Fax: +45 7488 8100
Email: heating.solutions@danfoss.com
www.heating.danfoss.com
Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products
already on order provided that such alterations can be made without subsequential changes being necessary in specifications already agreed. All trademarks in this material are property of the respective
companies. Danfoss Heating Solutions and the Danfoss Heating Solutions logotype are trademarks of Danfoss A/S. All rights reserved.
VUE2D202 Produced by Danfoss Heating Solutions © 08/2016
6
ASV-I/M measuring KIT for PFM100
1 set 003L8274
