1 AC input busbar 3 Brake/regen terminals (optional)
2 Input terminals 4 Output terminals
Illustration 8.11 Power Terminals in E-sized Drives
Whenever possible, perform these procedures with a split bus power supply. For more information, see
chapter 9.1.1 Overview.
Test Procedures
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
