Danfoss PTU 025 Service Guide

1
4
5
6
7
8
9
10
11
130BF850.10
3
2
1 Balance/high frequency card 7 DC(+) plate
2 Insulator sheet 2 8 Insulator sheet 3
3 Midplate 1 9 Midplate 2
4 Insulator sheet 1 10 Capacitor locking panel
5 DC(-) plate 11 Standard DC capacitors
6 Plastic alignment cap – –
Illustration 10.14 DC Capacitors, 690 V AC Unit
D1h/D3h/D5h/D6h/J8 Drive Di... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 161
10 10
