1
3
4
2
130BF848.10
1 Contactor 3 Contactor bracket
2 Disconnect 4 A1/A2 contactor coil terminals
Illustration 10.33 D6h Contactor and Disconnect
D1h/D3h/D5h/D6h/J8 Drive Di... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 183
