Danfoss PTU 025 Service Guide

1
10
8
6
5
4
7
3
2
130BF884.10
9
1 Top nut (13 mm) 6 Power terminal mounting plate
2 AC input busbar 7 Brake busbar (optional)
3 Bottom nut (13 mm) 8 U motor busbar
4 Fuse spacer 9 Brake terminal (optional)
5 Mains input terminal 10 Motor terminal block
Illustration 11.3 AC Input Busbars and Power Terminals
D2h/D4h/D7h/D8h/J9 Unit Dis... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 193
