130BF854.10
1 Balance/high frequency card 6 Insulator sheet
2 Capacitor bank cover 7 DC center plates
3 DC(+) plate 8 Capacitor locking panel
4 Insulator sheet 9 Standard DC capacitors
5 DC(-) plate – –
Illustration 11.15 Standard DC Capacitors, 690 V AC Unit
