E
F
B
C
D
0 0.0[ ]
51 2.0[ ]
226 8.9[ ]
266 10.5[ ]
441 17.4[ ]
0 0.0[ ]
28 1.1[ ]
167 6.6[ ]
195 7.7[ ]
A
0 0.0[ ]
176FA279.11
Illustration 3.24 IP21 (NEMA type 1) and IP54 (NEMA type 12) Enclosure Power Connection Position of Disconnect Switch
Enclosure
types
Unit type Dimensions [mm]/(inch)
E1
IP54/IP21 UL AND NEMA1/NEMA12
250/315 kW (400 V) AND 355/450-500/630
KW (690 V)
396 (15.6) 267 (10.5) 332 (13.1) 397 (15.6) 528 (20.8) N/A
315/355-400/450 kW (400 V) 408 (16.1) 246 (9.7) 326 (12.8) 406 (16.0) 419 (16.5) 459 (18.1)
Table 3.8 Dimensions for Disconnect Terminal
Mechanical Installation
VLT HVAC Drive FC 102 Operating Instructions
26 MG11F402 - Rev. 2013-12-16
