Danfoss PVG 16 Service And Parts Manual

PVP parts list
Item Description Code number Letter
A B C D E F G H I J
1 Relief valve service tool 155L6494 - - - - - - - - - -
2 Sealed adjusting screw 155L6489 - - - - - - - - - -
3 Plastic plug (black) 155L6168 50 50 50 50 50 50 50 50 50 50
4 Pilot supply for PVE (13.5 bar) 155L5157 - - 1 1 1 1 1 1 1 -
4 Pilot supply for PVH/PVHC (25 bar) 11077272 - - - - - - - - - 1
5 Relief valve 155L6495 1 1 1 1 1 1 1 1 1 1
6 Plastic plug - 2 2 2 2 2 2 2 2 2 2
7 T0 plug - - - - 1 - - - - - -
8 Conversion kit (open→closed,
closed→open)
155L5152 - - - - - - - - - -
9 Orifice Ø1.0, bonded seal and
plug for closed center
- - - - - - - - - - -
10 M6 plug for open center 155L5153 1 1 1 1 1 1 1 1 1 1
11 Plug with O-ring - 2 2 2 3 2 3 2 3 3 3
12 Plastic plug - - - - 1 1 1 - 1 - -
13 Inlet compensator assembly - 1 1 1 1 1 1 1 1 1 1
14 Plastic plug - 1 1 1 1 1 1 1 1 1 1
15 Locking pin - 1 1 1 1 1 1 1 1 1 1
16 Orifice M6 Ø1.0 - 1 1 1 1 1 1 1 1 1 1
17 PVP inlet module - 1 1 1 1 1 1 1 1 1 1
Item Description Code number Letter
K L M N O P Q R S T
1 Relief valve service tool 155L6494 - - - - - - - - - -
2 Sealed adjusting screw 155L6489 - - - - - - - - - -
3 Plastic plug (black) 155L6168 1 1 1 1 1 1 1 1 1 1
4 Pilot supply for PVE (13.5 bar) 155L5157 - - - 1 1 1 1 1 - -
4 Pilot supply for PVH/PVHC (25 bar) 11077272 1 - - - - - - - 1 1
5 Relief valve 155L6495 50 50 50 50 50 50 50 50 50 50
6 Plastic plug - 2 2 2 2 2 2 2 2 2 2
7 T0 plug - - - - - 1 - - - - -
8 Conversion kit (open→closed,
closed→open)
155L5152 - - - - - - - - - -
9 Orifice Ø1.0, bonded seal and
plug for closed center
- - 1 1 1 1 1 1 1 1 1
10 M6 plug for open center 155L5153 1 - - - - - - - - -
11 Plug with O-ring - 2 2 2 2 3 2 3 3 2 3
12 Plastic plug - - - - - 1 - 1 - - -
13 Inlet compensator assembly - 1 1 1 1 1 1 1 1 1 1
14 Plastic plug - 1 1 1 1 1 1 1 1 1 1
15 Locking pin - 1 1 1 1 1 1 1 1 1 1
16 Orifice M6 Ø1.0 - 1 1 1 1 1 1 1 1 1 1
17 PVP inlet module - 1 1 1 1 1 1 1 1 1 1
Service and Parts Manual
PVG 16/32/128/256
Service Parts
©
Danfoss | October 2018 AX284661889190en-000101 | 77
