Accessories
Rotolock adaptor
Gaskets
Solder sleeves
Solder sleeve adaptator set
Type Code n° Description Application Packaging
Pack
size
7765005 Solder sleeve adapter set (1"3/4~1"1/8), (1"1/4~3/4") SM/SZ084-090-100 Multipack 6
120Z0405 Solder sleeve adapter set (1"3/4~1"3/8), (1"1/4~7/8")
SM110-112-120-124-148-161&SM/SZ147&
SZ110-120-148-161
Multipack 8
7765006* Solder sleeve adapter set (1"3/4~1"3/8), (1"1/4~3/4")
SM110-112-120-124-148-161&SM/SZ147&
SZ110-120-148-161
Multipack 6
7765028 Solder sleeve adapter set (2"1/4~1"5/8), (1"3/4~1"1/8) SM/SZ175-185, SY 240-300 Multipack 6
* Diameter restrictor
Type Code n° Description Application Packaging
Pack
size
120Z0366 Adaptor (1"1/4 Rotolock -3/4" ODS) Models with 3/4" ODF Multipack 10
120Z0367 Adaptor (1"1/4 Rotolock - 7/8" ODS) Models with 7/8" ODF Multipack 10
120Z0364 Adaptor (1"3/4 Rotolock -1"1/8 ODS) Models with 1"1/8 ODF Multipack 10
120Z0431 Adaptor (1"3/4 Rotolock -1"3/8" ODS) Models with 1"3/8 ODF Multipack 10
120Z0432 Adaptor (2"1/4 Rotolock -1"5/8 ODS) Models with1"5/8 ODF Multipack 10
Type Code n° Description Application Packaging
Pack
size
G09 8156131 Gasket, 1"1/4 Models with 1"1/4 rotolock connection Multipack 10
G09 7956002 Gasket, 1"1/4 Models with 1"1/4 rotolock connection Industry pack 50
G07 8156132 Gasket, 1"3/4 Models with 1"3/4 rotolock connection Multipack 10
G07 7956003 Gasket, 1"3/4 Models with 1"3/4 rotolock connection Industry pack 50
G08 8156133 Gasket, 2"1/4 Models with 2"1/4 rotolock connection Multipack 10
G08 7956004 Gasket, 2"1/4 Models with 2"1/4 rotolock connection Industry pack 50
8156013 Gasket set 1"1/4 - 1"3/4 2"1/4, OSG gaskets black & white All Rotolock models Multipack 10
Type Code n° Description Application Packaging
Pack
size
P02 8153004 Solder sleeve P02 (1"3/4 Rotolock - 1"1/8 ODF) Models with 1"3/4 rotolock connection Multipack 10
P03 8153006 Solder sleeve P03 (2"1/4 Rotolock - 1"5/8 ODF) Models with 2"1/4 rotolock connection Multipack 10
P04 8153008 Solder sleeve P04 (1"1/4 Rotolock - 3/4" ODF) Models with 1"1/4 rotolock connection Multipack 10
P05 8153012 Rotolock connector P05 (1"1/4 Rotolock - 7/8" ODF) Models with 1"1/4 rotolock connection Multipack 10
P07 8153013 Solder sleeve P07 (1"3/4 Rotolock - 7/8" ODF) Models with 1"3/4 rotolock connection Multipack 10
P08 8153005 Solder sleeve P08 (2"1/4 Rotolock - 1"3/8 ODF) Models with 2"1/4 rotolock connection Multipack 10
P10 8153003 Solder sleeve P10 (1"3/4 Rotolock - 1"3/8 ODF) Models with 1"3/4 rotolock connection Multipack 10
