Technical specications
Model
Nominal
Cap. 60 Hz
Nominal cooling
capacity
Power input COP E.E.R.
Swept
volume
Displace-
ment 
Oil
charge
Net
weight 
TR W Btu/h kW W/W Btu/h /W cm
3
/rev m
3
/h dm
3
kg
R22 SINGLE
SM084 7 24600 84000 7.40 3.34 11.4 114.5 24.1 3.25 64
SM090 7.5 26400 90100 7. 80 3.37 11.5 120.5 25.3 3.25 65
SM100 8 27500 93900 8.10 3.38 11.5 127.2 26.7 3.25 65
SM110 9 31600 107800 9.30 3.38 11.5 144.2 30.3 3.25 73
SM112 9.5 34000 116000 9.60 3.53 12.1 151.5 31.8 3.30 64
SM120 10 36700 125300 10.80 3.40 11.6 166.6 35.0 3.25 73
SM124 10.5 37700 128700 10.60 3.56 12.2 169.5 35.6 3.30 64
SM147 12 43600 148800 12.20 3.58 12.2 193.5 40.6 3.30 67
SM148 12 43800 149500 13.00 3.37 11.5 199.0 41.8 3.60 88
SM161 13 47600 162500 14.10 3.39 11.6 216.6 45.5 3.60 88
SM175 14 51100 174400 15.30 3.34 11.4 233.0 48.9 6.20 100
SM/SY185 15 55300 188700 16.30 3.39 11.6 249.9 52.5 6.20 100
SY240 20 74100 252900 22.10 3.35 11.4 347.8 73.0 8.00 150
SY300 25 94500 322500 27.50 3.43 11.7 437. 5 91.9 8.00 157
SY380 30 115300 393500 33.40 3.46 11.8 531.2 111.6 8.40 158
R407C SINGLE
SZ084 7 22500 76800 7.10 3.19 10.9 114. 5 24.1 3.25 64
SZ090 7.5 24400 83300 7. 6 0 3.20 10.9 120.5 25.3 3.25 65
SZ100 8 26500 90400 8.20 3.24 11.1 127.2 26.7 3.25 65
SZ110 9 30100 102700 9.30 3.24 11.1 144.2 30.3 3.25 73
SZ120 10 34800 118800 10.70 3.24 11.1 166.6 35.0 3.25 73
SZ147 12 42300 144328 12.03 3.52 12.0 193.5 40.6 3.30 67
SZ148 12 42600 145400 13.30 3.19 10.9 199.0 41.8 3.60 88
SZ161 13 46000 157000 14.30 3.21 11.0 216.6 45.5 3.60 88
SZ175 14 48700 166200 15.30 3.19 10.9 233.0 48.9 6.20 100
SZ185 15 51800 176800 16.40 3.15 10.8 249.9 52.5 6.20 100
SY240 20 71100 242700 22.70 3.14 10.7 347.8 73.0 8.00 150
SY300 25 87900 300000 27.50 3.20 10.9 437.5 91.9 8.00 157
SY380 30 107300 366200 33.50 3.20 10.9 531.2 111.6 8.40 158
R134a SINGLE
SZ084 7 16700 57100 5.06 3.31 11. 29 114. 5 24.1 3.25 64
SZ090 7.5 17700 60300 5.33 3.31 11. 31 120.5 25.3 3.25 65
SZ100 8 18700 63800 5.64 3.32 11. 32 127.2 26.7 3.25 65
SZ110 9 21300 72800 6.41 3.33 11.36 144.2 30.3 3.25 73
SZ120 10 24800 84700 7.43 3.34 11.4 0 166.6 35.0 3.25 73
SZ147 12 28300 96600 8.04 3.52 12.02 193.5 40.6 3.25 67
SZ148 12 29000 99100 9.37 3.10 10.57 199.0 41.8 3.60 88
SZ161 13 31500 107500 9.68 3.25 11.10 216.6 45.5 3.60 88
SZ175 14 34400 117300 10.39 3.31 11.29 233 48.9 6.20 100
SZ185 15 36600 124800 11.10 3.30 11. 25 249.9 52.5 6.20 100
SY240 20 49400 168600 15.37 3.21 10.97 347.8 73.0 8.00 150
SY300 25 60600 206900 19.61 3.09 10.55 437.5 91.9 8.00 157
SY380 30 75800 258600 23.22 3.26 11.14 531.2 111.6 8.40 158
R513A SINGLE
SZ148 12 28861 98477 9.32 3.10 10.57 199.0 41.8 3.60 88
SZ161 13 32617 111292 10.01 3.26 11.12 216.6 45.5 3.60 88
SZ175 14 33952 115847 10.58 3.21 10.94 233.0 48.9 6.20 100
SZ185 15 38009 129690 11.33 3.35 11.45 249.9 52.5 6.20 100
SY240 20 51208 174727 15.9 3.22 10.99 347.8 73.0 8.00 150
SY300 25 64441 219879 19.5 3.30 11. 25 437. 5 91.9 8.00 157
SY380 30 69586 79439 24.7 3.22 10.99 531.2 111.6 8.40 158
TR = Ton of Refrigeration  Displacement at nominal speed: 2900 rpm at 50 Hz, 3500 rpm at 60Hz
COP = Coecient Of Performance  Net weight with oil charge
EER = Energy Eciency Ratio
60 Hz data
Subject to modication without prior notication
Refrigerant R22/R134a/R513A R407C
Frequency 60 Hz 60 Hz
Standard rating conditions ARI standard conditions -
Evaporating temperature 7.2 °C 7.2 °C (dew point)
Condensing temperature 54.4 °C 54.4 °C (dew point)
Sub-cooling 8.3 K 8.3 K
Superheat 11.1 K 11.1 K
Rating conditions
For regular updates and detailed capacities, please refer to Coolselector®2 www.coolselector.danfoss.com
8 AB237986441643en-010801
