Technical specications
Model
Nominal
Cap. 60 Hz
Nominal cooling capacity Power input COP E.E.R.
Swept
volume
Displacement

Oil
charge
Net
weight 
TR W Btu/h kW W/W Btu/h /W cm
3
/rev m
3
/h dm
3
kg
R22 SINGLE
SM084 7 20 400 69 600 6.12 3.33 11.4 114. 5 19.9 3.25 64
SM090 7.5 21 800 74 400 6.54 3.33 11.4 120.5 21.0 3.25 65
SM100 8 23 100 78 800 6.96 3.33 11.4 127.2 22.1 3.25 65
SM110 9 25 900 88 400 7.82 3.32 11. 3 144.2 25.1 3.25 73
SM112 9.5 27 600 94 200 7.92 3.49 11.9 151.5 26.4 3.30 64
SM120 10 30 100 102 700 8.96 3.36 11.5 166.6 29.0 3.25 73
SM124 10 31 200 106 500 8.75 3.56 12.2 169.5 29.5 3.30 64
SM147 12 36 000 122 900 10.08 3.57 12.2 193.5 33.7 3.30 67
SM148 12 36 100 123 200 10.8 3.34 11. 4 199.0 34.6 3.60 88
SM161 13 39 000 133 100 11.59 3.37 11.5 216.6 37.7 3.60 88
SM175 14 42 000 143 300 12.47 3.37 11.5 233.0 40.5 6.20 100
SM/SY185 15 45 500 155 300 13.62 3.34 11.4 249.9 43.5 6.20 100
SY240 20 61 200 208 900 18.2 3.36 11.5 347.8 60.5 8.00 150
SY300 25 78 200 266 900 22.83 3.43 11.7 437. 5 76.1 8.00 157
SY380 30 94 500 322 500 27. 33 3.46 11.8 531.2 92.4 8.40 158
R407C SINGLE
SZ084 7 19 300 65 900 6.13 3.15 10.8 114. 5 19.9 3.25 64
SZ090 7.5 20 400 69 600 6.45 3.16 10.8 120.5 21.0 3.25 65
SZ100 8 21 600 73 700 6.84 3.15 10.8 127.2 22.1 3.25 65
SZ110 9 24 600 84 000 7.76 3.17 10.8 144.2 25.1 3.25 73
SZ120 10 28 600 97 600 8.99 3.17 10.8 166.6 29.0 3.25 73
SZ147 12 34 900 119 079 9.92 3.52 12.0 193.5 33.7 3.30 67
SZ148 12 35 100 119 8 0 0 10.99 3.19 10.9 199.0 34.6 3.60 88
SZ161 13 38 000 129 700 11. 84 3.21 11.0 216.6 37.7 3.60 88
SZ175 14 40 100 136 900 12.67 3.17 10.8 233.0 40.5 6.20 100
SZ185 15 43 100 147 100 13.62 3.16 10.8 249.9 43.5 6.20 100
SY240 20 59 100 201 700 18.55 3.19 10.9 347.8 60.5 8.00 150
SY300 25 72 700 248 100 22.73 3.20 10.9 437.5 76.1 8.00 157
SY380 30 89 600 305 800 27. 59 3.25 11.1 531.2 92.4 8.40 158
R134a SINGLE
SZ084 7 12100 41100 3.83 3.15 10.75 114. 5 19.9 3.25 64
SZ090 7.5 12900 43900 4.08 3.15 10.77 120.5 21.0 3.25 65
SZ100 8 13800 47000 4.36 3.16 10.78 127. 2 22.1 3.25 65
SZ110 9 15600 53100 4.90 3.17 10.83 144.2 25.1 3.25 73
SZ120 10 17900 61200 5.62 3.19 10.89 166.6 29.0 3.25 73
SZ147 12 20800
71000 6.13 3.40 11. 59 193.5 33.7 3.25 67
SZ148 12 21500 73400 6.96 3.09 10.55 199.0 34.6 3.60 88
SZ161 13 23000 78400 7.30 3.15 10.74 216.6 37.7 3.60 88
SZ175 14 25300 86200 7.90 3.20 10.91 233.0 40.5 6.20 100
SZ185 15 26900 91700 8.41 3.20 10.91 249.9 43.5 6.20 100
SY240 20 35600 121600 11.60 3.07 10.48 347. 8 60.5 8.00 150
SY300 25 44400 151700 14.43 3.08 10.51 437. 5 76.1 8.00 157
SY380 30 55800 190500 17.26 3.23 11.04 531.2 92.4 8.40 158
R513A SINGLE
SZ148 12 20665 70512 6.96 2.97 10.13 199.0 34.6 3.60 88
SZ161 13 23634 80642 7. 54 3.14 10.70 216.6 37.7 3.60 88
SZ175 14 24413 83299 8.07 3.03 10.32 233.0 40.5 6.20 100
SZ185 15 27438 93621 8.64 3.18 10.84 249.9 43.5 6.20 100
SY240 20 37450 127783 12.1 3.10 10.59 347.8 60.5 8.00 150
SY300 25 47497 162065 14.7 3.22 10.99 437. 5 76.1 8.00 157
SY380 30 58537 199734 18.1 3.23 11.03 531.2 92.4 8.40 158
TR = Ton of Refrigeration  Displacement at nominal speed: 2900 rpm at 50 Hz, 3500 rpm at 60Hz
COP = Coecient Of Performance  Net weight with oil charge
EER = Energy Eciency Ratio
50 Hz data
Subject to modication without prior notication
Rating conditions
Refrigerant R22 R134a/R513A R407C
Frequency 50 Hz 50 Hz 50 Hz
Standard rating conditions ARI EN12900 -
Evaporating temperature 7.2 °C 5 °C 7.2 °C (dew point)
Condensing temperature 54.4 °C 50 °C 54.4 °C (dew point)
Sub-cooling 8.3 K 10 K 8.3 K
Superheat 11.1 K 0 K 11.1 K
For regular updates and detailed capacities, please refer to Coolselector®2 www.coolselector.danfoss.com
7AB237986441643en-010801
